686-ASY-3500 & 686-ASY-3500P

This Paired Row Opener Fits: Seed Hawk Inc.* / Väderstad

Fertilizer Type: Granular + Liquid Phos

Tube Size: Seed Tube: 1-1/4” (32 mm) O.D. Liq. Phos.: 3/16” (5 mm) O.D. This can be converted to work with 1/4” (6 mm) I.D. delivery hoses with 880-ASY-1010.

Tip Options: 3” (76 mm) cast chrome tip with carbide insert on the nose to fracture the ground. Carbide inserts on the underside of the wings maintain a sharp cutting edge. Assembly includes the tip.

Overview: The seed shank is in-line with the fertilizer shank. Extra hard surfacing on critical wear areas increases the life of the holder.  For Liquid Phosphorus option order 686-ASY-3500P.

Notes: Use 1/2” x 2” Grade 8 Hex Head bolts to install these openers. Sold separately.

*Drawing for illustration purposes only. All measurements shown are approximate. Results may vary with multiple factors including soil conditions, ground speed, application rates, fan speeds and more. In less than ideal conditions, mixing between seed and fertilizer may occur. For more information please refer to our precautions and risk factors.

*All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Seed Hawk Inc. and Väderstad and any other use and/or mentions of their name and/or product designations are the property and registered trademarks of Seed Hawk Inc. / Väderstad Holding. For more information please view our Legal Notice.
